Powerful Tungsten Carbide Strips / Tungsten Carbide Block With Higher Strength
Product Details:
| Place of Origin: | Zhuzhou City,Hunan Provience,P.R.China |
| Brand Name: | Ri Xing |
| Certification: | ISO9001:2008 |
| Model Number: | YG6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5KG |
|---|---|
| Price: | USD + 60~55 + KG |
| Packaging Details: | paper box,carton, |
| Delivery Time: | 10-15 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 Tons per month |
|
Detail Information |
|||
| Product Name: | Carbide Strips | Keywords: | Carbide Strips |
|---|---|---|---|
| Surface: | Sand Blasting | MOQ: | Accepted |
| Material: | 100% Tungsten Carbide Virgin Material | ||
| High Light: | tungsten carbide block,tungsten carbide plate |
||
Product Description
Powerful Tungsten Carbide Strips / Tungsten Carbide Block With Higher Strength
Grade&Application of carbide strip
carbide strip,carbide strip,tungsten carbide strips,carbide strips,tungsten carbide bar
Grades of tungsten carbide strips
|
Grade
|
Density |
Hardness HRA | T.R.S MP a | Performance& application recommended |
| YG6 | 14.9 | 90.5 | 2400 |
Good wear resistance, suitable for machining hard wood, raw wood, aluminum section bar, brass rod and cast iron
|
| YG6A | 14.85 | 92.5 | 2000 |
Wear resistance higher than YM6, suitable for machining hard wood, raw wood, aluminum bar, brass rod and cast iron
|
| YG8 | 14.7 | 89.8 | 2800 |
High wear and impact resistance, suitable for machining dry wood, soft wood and non-ferrous metal section bar
|
| YS2T | 14.25 | 92.0 | 2400 |
Fine grain alloy, with high wear resistance, bending strength, bonding resistance and thermal strength, it is suitable for machining refractory alloys, stainless steel, high manganese steel, etc.
|
| YG10X | 14.45 | 91.8 | 3000 |
wear resistance and strength comparatively higher, suitable for machining cast iron, non- ferrous metal and non- metallid materials
|
| Type | T*W*L (mm) | T (mm) | W (mm) | L (mm) |
| FS05 | T x 5 x 320 | 2.0~15.0 | 5 | 320 |
| FS06 | T x 6 x 320 | 2.0~15.0 | 6 | 320 |
| FS07 | T x 7 x 320 | 2.0~15.0 | 7 | 320 |
| FS08 | T x 8 x 320 | 2.0~15.0 | 8 | 320 |
| FS09 | T x 9 x 320 | 2.0~15.0 | 9 | 320 |
| FS10 | T x 10 x 320 | 2.0~15.0 | 10 | 320 |
| FS11 | T x 11 x 320 | 2.0~15.0 | 11 | 320 |
| FS12 | T x 12 x 320 | 2.0~15.0 | 12 | 320 |
| FS13 | T x 13 x 320 | 2.0~15.0 | 13 | 320 |
| FS14 | T x 14 x 320 | 2.0~15.0 | 14 | 320 |
| FS15 | T x 15 x 320 | 2.0~15.0 | 15 | 320 |
| FS16 | T x 16 x 320 | 2.0~15.0 | 16 | 320 |
| FS17 | T x 17 x 320 | 2.0~15.0 | 17 | 320 |
| FS18 | T x 18 x 320 | 2.0~15.0 | 18 | 320 |
| FS19 | T x 19 x 320 | 2.0~15.0 | 19 | 320 |
| FS20 | T x 20 x 320 | 2.0~15.0 | 20 | 320 |
| FS22 | T x 22 x 320 | 2.0~15.0 | 22 | 320 |
| FS25 | T x 25 x 320 | 2.0~15.0 | 25 | 320 |
| FS28 | T x 28 x 320 | 2.0~15.0 | 28 | 320 |
| FS30 | T x 30 x 320 | 2.0~15.0 | 30 | 320 |
| FS32 | T x 32 x 320 | 2.0~15.0 | 32 | 320 |
| FS35 | T x 35 x 320 | 2.0~15.0 | 35 | 320 |
| FS40 | T x 40 x 320 | 2.0~15.0 | 40 | 320 |
| FS45 | T x 45 x 320 | 2.0~15.0 | 45 | 320 |
| FS50 | T x 50 x 320 | 2.0~15.0 | 50 | 320 |
| FS55 | T x 55 x 320 | 2.0~15.0 | 55 | 320 |
| Tolerance (mm) | ||
| L | >150 | -0~+L*2% |
| W | ≤8.0 | -0~+0.35 |
| 8.0~25.0 | -0~+0.50 | |
| 25.0~35.0 | -0~+0.70 | |
| >35.0 | -0~+1.20 | |
| T | ≤15.0 | -0~+0.40 |
| Flatness (mm) | ||
| W | ≤20.0 | ≤0.50 |
| >20.0 | ≤0.60 | |
Application of carbide strips
Tungsten carbide strips is used for hard wood, used for processing original wood, aluminum section bar, brass rod and cast iron
Production of carbide strip
1. Highproduction capacity and advanced technologies. Zhuzhou Mingri has mature technologies and process for tungsten carbide strip production. We have 60 t TPA pressing machine to ensure good quality of green compacts, and HIP sintering furnace in which 1000 kilograms of tungsten carbide strip can be sintered each time. We guarantee good and consistent quality of all our products.
2. A team with advanced technologies and strong R&D capacity. We’ve set expert engineers to
track the application of this type of products and develop new materials with better properties. We keep constant communications with our customers,and provide enthusiastic and considerate service.
3.Independent mold designing team and production workshop, to support our product-customizing with high efficiency and durable quality.
4. Successful cases.Our company has already supplied several companies with tons of tungsten carbide strip and gained good reputation.
Packing and delivery of carbide strip
step 1, wrapped tungsten carbide strip in paper to avoid tungsten carbide strip to broke
step 2, put the tungsten carbide strip in inner small carton box
step 3, put the inner box into outter carton and fill the carton with foamed plastic
step 4, wrap the carton with packaging tapestep
step 5, you can choose any delivery way such as DHL,TNT,UPS ect.
company information
carbide strip,carbide strip,tungsten carbide strips,carbide strips,tungsten carbide bar
Zhuzhou Mingri Tungsten Carbide Co., Ltd. was established in May of 2001 with the investment of RMB 40 million. We have up-to-date production machine line and a lot of technicians.
Zhuzhou MingRi Cemented carbide co.,ltd is located in the tungsten carbide hometown , convenient transportation, from changsha airport just 40 minutes, wuhan just 1.5 hour, from guangzhou just 2 hours. A favorable peripheral environment for cemented carbide manufacturing provides a natural barrier. Convenient traffic for tomorrow's internationalization laid a wide road.
We specialize in various of tungsten carbide products. Our products are sold to the UK, Europe, Japan, Korea, Taiwan area and Southeast Asia.
We strive for long-term business relationships with all customers, and look forward to being your first choice for your source of carbide.
