Polished Surface Tungsten Carbide Die for Grinding Application with OEM Customizable Options
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | rixin |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | $0.49 |
|
Detail Information |
|||
| Material: | WC+Cobalt | Grade: | G15, YG20, YG20C, YG22C, YG25C, GT55, ML40, ML100, ST7, VA90, C5 |
|---|---|---|---|
| TRS: | > 3000 N/mm3 | Hardness: | 85-92HRA |
| Density: | 13.1-14.4 G/cm3 | Surface Treatment: | Coated, Grinding, Polishing, Sand-blasted |
| Outer Diameter: | 10-100mm | Inner Diameter: | 2-30mm |
| Length: | 10-60mm | Bending Strength: | 2420-3100 MPα |
| Impact Resistance: | High | Wear Resistance: | Good |
| Power Source: | Electric | Engine Type: | Electric |
| Tolerance: | Blank, Semi-finished, Finished | ||
| Highlight: | Polished Surface Tungsten Carbide Die,OEM Customizable Carbide Pellet Die,Grinding Application Carbide Mold |
||
Product Description
Cemented Tungsten Carbide Pellet Die Mold
High-quality polished surface pellet die molds for grinding applications with OEM customization options.
| Item | Tungsten carbide die |
| Grade | YG6, YG8, YG11, YG12, YG15, YG20, YG20C, YG22C, YG25C, GT55, ML40, ML100, ST7, VA90, C5 |
| Sizes | Standard or customized |
| Brand | Rixin |
| Country of Origin | Zhuzhou, China |
| Usage | Die casting mould, punch dies, wire drawing die, machine mold, progressive die, extrusion die, press mold, mould parts, trimming die, cold heading die, forging mold, cold forming die |
- Tungsten carbide die blanks are widely used for making finished die casting moulds, punch dies, wire drawing dies, machine molds, progressive dies, extrusion dies, press molds, mould parts, trimming dies, cold heading dies, forging molds, and cold forming dies
- Extensive inventory of available moulds for various sizes of carbide dies, providing significant cost savings
- Comprehensive range of stable carbide die grades with superior cost performance compared to industry leaders
HIP Sintered Tungsten Carbide Die Pellet Moulds - Grades & Specifications
| Grade | Density (g/cm³) | T.R.S (MPa) | Hardness (HRA) | Properties & Applications | Approx Grades in China |
|---|---|---|---|---|---|
| A | 13.5 | 3000 | 83.5 | Good wear resistance and bending strength. Preferred for nut forming dies and high impact-resistant dies. | -- |
| YM11 | 14.4 | 2420 | 88.5 | Forming or stamping dies for metal powders and non-metal powders. | YG11 |
| YM15 | 14.0 | 2500 | 87.5 | Suitable for drawing steel tubes and rods under high compression ratio, manufacturing upsetting, punching and forging tools under large stress. | YG15 |
| YM20 | 13.5 | 2800 | 85.5 | Suitable for manufacturing punching dies for watch parts, leaf spring of musical instruments, battery jars, small sized steel balls, screws, screw caps. | YG20 |
| ML32 | 13.9 | 2750 | 85.5 | Suitable for impact-resistant forging dies. | YG16C |
| ML36 | 13.7 | 2800 | 84.5 | Suitable for impact-resistant forging dies, hot-forging dies and finishing rollers. | YG18C |
| ML40 | 13.5 | 2850 | 83.5 | Suitable for wear resistant or impact resistant dies. | YG20C ZL40.2 |
| ML50 | 13.3 | 2900 | 83.0 | Suitable for nut forming dies and high impact-resistant dies. | YG22C ZL40.5 |
| ML60 | 13.1 | 2950 | 82.5 | Suitable for stainless screw dies and semifinishing rollers. | YG25C ZL40B |
| ML80 | 13.1 | 3050 | 83.4 | Suitable for screw cap forming dies with high strength (highest impact-resistant forging dies). | YG25C GT55 |
| ML100 | 13.1 | 3100 | 84 | Suitable for screw cap forming dies with high strength (highest impact-resistant forging dies). | GT55 plus |
Other grades of cemented carbide blanks for cold-forging dies available upon customer request.
HIP Sintered Tungsten Carbide Die Pellet Moulds - Dimensions
D: 10-100mm
d: 2-30mm
L: 10-60mm
Other sizes available according to customer requirements.
Packaging & Delivery
| Packing | Paper + paper boxes + exported wooden cartons or paper cases. Custom packaging available per buyer requirements. |
| Shipping | UPS, TNT, EMS, Fedex, DHL, or as requested |
| Delivery | 7-10 days after confirming all details |
Main Products
Specialized in tungsten carbide profiles and dies, cutting tools, mining tools, wear parts, and non-standard customized tool parts with high industrial performance.
Company Information
Zhuzhou Mingri Cemented Carbide Co., Ltd was established in 2001 with $10 million investment, covering 33,300 square meters with 160 staff members. We hold 35 patents in invention, utility model and design, and maintain ISO9001:2015 Quality Certification and GB/T 24001-2004/ISO 14001:2004 Environmental Certification.
Workshop Facilities
Comprehensive manufacturing facilities including powder mixing, pressing, sintering, finishing, surface treatment, mould design workshops, and physical/chemical laboratories for inspection. Hundreds of updated equipment ensure monthly capacity of 50 tons and excellent quality standards.
Quality Assurance & Testing
All products undergo strict ultrasonic inspection to eliminate defects such as pores before shipping. High density, superior wear and impact resistance ensure extended product lifetime.
