    High Accuracy TC Slitter Blade Carbide Disc Cutter For Copper Foil Slitting Machine

    Product Details:

    Place of Origin: ZHUZHOU,HUNAN,CHINA
    Brand Name: RI XIN
    Certification: ISO9001:2008 ISO14001:2004
    Model Number: K10,K20,K30,K05,K40

    Payment & Shipping Terms:

    Minimum Order Quantity: 1KG
    Price: 32.68$/kg-68.59$/kg
    Packaging Details: First in small cartons filled with cotton, then in bigger cartons.
    Delivery Time: 7-20 days
    Payment Terms: L/C, D/A, D/P, T/T, L/C, T/T, Western Union
    Supply Ability: 50 Tons per month
    Get Best Price Contact Now

    Detail Information

    Features: High Hardness,Good Impact Resistance,High Wear Resistance Material: WC,Cobalt
    Grade: SH6A,SH10A,SH25,SH30,SH35 Application: Metal And Wood Cutting
    Surface Treatment: Polishing,sand-blasting Size: Customer Requst
    Hardness: 90.5 HRA TRS: 3200
    Character: High Precision And Wear Resistance Density: 14.1
    High Light:

    tungsten carbide blade

    ,

    carbide rotary cutter

    Product Description

    High Accuracy TC Slitter Blade Carbide Disc Cutter For Copper Foil Slitting Machine



    High Accuracy TC Slitter Blade for Copper Foil Slitting Machine



    1, Focusing on manufacturing tungsten carbide products over 18 years.

    2, Specialist manufacturer equipped with advanced processing machines and over160 technicians.

    3, Over 50 tons/month productivity to assure sustainable supply of products

    4, Owing mould workshop to design & produce moulds for nonstandard products, and with mould

    stocks over 10 thousand sets for different products.

    5, Full ability to accept OEM & ODM orders.

    6, Stringent quality control and quality consistency.

    7, Professional mechanical & chemical inspecting labs to control the quality of raw material and inspect physical & mechanical properties of finished products.





    Applications:



    For base paper rewinding top and bottom knives

    Tungsten carbide disc cutter is suitable for semifinishing the chilled cast iron, nonferrous

    metal and its alloy. It is also suitable for semifinishing and finishing the hardened steel

    and alloy steel.





    Grade and Applications:



    Grade

    Density

    g/cm3

    T.R.S

    MPα

    Hardness

    HRA

    Properties & Applications

    Approx

    Grades

    in China

    ISO
    SH6A 14.9 1850 92

    Fine grain alloy, good wear resistance. It is suitable for machining the chilled cast iron, nonferrous metal and its alloy. It is also suitable for semifinishing and finishing the hardened steel and alloy steel.

    YG6A K10
    SH10A 14.8 2450 90.5

    High wear resistance and bending strength, suitable for disc cutters in electronics industry.

    _ K20-K30
    SH25 14.8 2200 89.5

    Higher strength, impact and shock resistance than SH6A, but lower in wear resistance and cutting speed. It is suitable for rough machining cast iron, nonferrous metal and its alloy as well as non metallic materials at low cutting speed.

    YG8 K20
    SH30 14.7 2320 89.5

    Higher strength, impact and shock resistance than SH25, but lower in wear resistance and cutting speed. It is suitable for rough machining cast iron, nonferrous metal and its alloy as well as non metallic materials at low cutting speed.

    YG8 K20
    SH35 14.5 2200 91

    Fine grain alloy with good wear resistance. It is suitable for machining hard wood, plywood,PCB, PVC and metals.

    YG10X K10-K20
    SH40 14.5 2480 92

    Fine grade alloy with high wear resistance, bending strength, bonding resistance and thermal strength. It is suitable for machining plywood, PCB, PVC,refractory alloys, stainless steel and high manganese steel etc.

    YS2T K10-K20
    SH50 14.3 2420 90

    Moderate wear resistance and bending strength ,suitable for machining steel alloy etc.

    _

    K20-K30





    Common size:OD*ID*T (mm)



    Characteristic :The blade has good appearance,high consistency and wear resisitance,the cutting edge can pass the inspection of enlarging 200 times without chips on it.Guranteed cutting quality,long working life,also the frequency of replacing blades is very low with high cost performance



    High Accuracy TC Slitter Blade Carbide Disc Cutter For Copper Foil Slitting Machine 0



    1, Soon after the order is confirmed, tungsten carbide steel knife products will start to prepare the RTP powder as per customer’s requirement with our wet-grinding machine

    2, Before mass production, we need to do a trial pressing and sintering using every mould, and we check the appearances and the sizes of tungsten carbide steel knife samples with micrometer, projectors etc. to ensure that the requirements of the drawings can be met before batch production

    3, Bulk production ,press the raw materials to shape blanks,and all tungsten carbide steel knife blanks must be passed by semi finished inspection,


    4, Then sinter blanks to finish (HIP) and finished products inspection, we have 10 sets of vacuum sintering furnace and 2 sets of HIP in the factory ensure the best quality and production capacity.

    High Accuracy TC Slitter Blade Carbide Disc Cutter For Copper Foil Slitting Machine 1

    High Accuracy TC Slitter Blade Carbide Disc Cutter For Copper Foil Slitting Machine 2

    Packing and delivery:

    1. Rubber protector for cutting edges, blade in bubble pack, carton case.

    Max 10 pcs blades in one carton case

    2. Exterior packaging: carton or wooden case

    3. Other packaging upon your request

    4. We also have the professional agents shipping our products to the customers.



    FAQ



    Q1 : Are you manufacturer or trading company ?

    We are manufacturer of tungsten carbide products.


    Q2: Where is your factory located ?

    We are located in Zhuzhou city, Hunan province where is 1 hours-driving from Changsha airport


    Q3: Is the price Competitive?

    zhuzhou mingri offer reliable products with good price.


    Q4: Are the products High Quality?

    Yes. Raw material will be tested before bulk production, and we will check the phys-ical properties, shape and tolerance for ensuring qualified products before shipping.


    Q5: How to place an order of tungsten carbide products?

    1. Fill your Order List in our online Inquiry System.
    (Also you can directly contact our salesperson by E-mail / Skype / Whats App)
    2. within 24-hours feedback when receiving your message.


    Q6: How we can trust your company ?

    We support Alibaba trade insurance , 100% products quality protection, 100% on-
    time shipment protection, 100% payment protection for your covered amount.


    Q7: What’s your delivery time ?

    For the normal type which we have mold it takes two weeks after receiving the
    advance payment.
    For the non standard which we do not have mold it takes 4 to 6 weeks when receiving
    the advance payment.

    Want to Know more details about this product
    I am interested in High Accuracy TC Slitter Blade Carbide Disc Cutter For Copper Foil Slitting Machine could you send me more details such as type, size, quantity, material, etc.
    Thanks!
    Waiting for your reply.
